Key Specifications / Features
The Side Entry Ball Valve features a robust bolted bonnet design, engineered to meet ISO 17292, API 608, and API 6D standards. Constructed with a durable ASTM A216 WCB body, this valve is designed for reliable performance in demanding industrial applications. With a 1/2-inch (DN15) size and Class 150 LB pressure rating, it ensures precise flow control, tight shut-off, and long service life. As a leading 2-piece floating ball valve manufacturer in China, we provide high-quality valves that combine superior materials, precision engineering, and compliance with international standards, delivering dependable solutions for oil, gas, water, and chemical pipelines.
Valve Description:
181203001 Floating Ball Valve
Design Standard: ISO 17292, API 608, API 6D
Structure: 2pcs body, Side Entry, Bolted Bonnet, Soft Seat
Sizes: 1/2 Inch, DN15, 15 mm
Pressure Rating: Class 150 LB, PN20
Bore Type: Full Bore or Reduced Bore
End Connection: RF, RTJ
Operation: Lever
Body Material: ASTM A105N or A350 LF2 or A182 F316, WCB, WCC, LCB, LCC, CF8, CF8M, CF3, CF3M, A995 4A, A995 5A, A995 6A, C95800
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55, A105+ENP, LF2+ENP
Seat Insert: RPTFE, DEVLON, NYLON, PEEK
Face to face: Manufacturer Standard
Test and inspection: API 598, API 6D
Key Features: Anti-static, Fire Safe, Anti-Blowout Stem
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 6 Inch (DN15 – DN150)
Pressure range: 150 - 300 LB
End connection: Flanged
Working temperature: -26°C - +210°C
Operation: Manual(lever), Pneumatic Actuator
