Aluminium Bronze Wafer Butterfly Valve, C95800, 48 IN, CL150

Key Specifications / Features

Model no. : BTV-187302021

We are a leading wafer butterfly valve manufacturer in China, specializing in large-size valves built for durability and performance. This 48-inch wafer butterfly valve features a robust body and disc made from aluminum bronze ASTM B148 C95800, ensuring excellent resistance to corrosion and seawater applications. It is rated for Class 150 LB pressure and equipped with a high-strength Monel K500 stem for enhanced reliability. Designed for ease of use, it comes with either lever or gear operation. Ideal for marine, offshore, and industrial environments requiring dependable flow control.

Detail Information

Valve Description:
187302021 High Performance Butterfly Valve
Design Standard: API 609 Category B, BS EN 593
Body Material: ASTM B148 C95800
Structure: Double Offset, Double Eccentric
Nominal Size: 48 Inch
Nominal Class: 150 LB
Seat Type: Soft Seat
Operation: Lever/Gear
Trim Material: ASTM B148 C95800
Seat: RPTFE, PPL
End Connection: Wafer/Lug/Flanged
Face to Face: API 609, BS EN 593
Test and Inspection: API 598, API 609
Key Features: Long working life for frequent operation(million cycling), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available, Aluminium bronze for sea water service


Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: Wafer/Lug/Flanged
Working Temperature: -26°C - +120°C (180°C for PPL Seat)
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
