API 600 Gate Valves, Al-bronze, Bolted Bonnet, 2-1/2 Inch

Name: API 600 Gate Valves, Al-bronze, Bolted Bonnet, 2-1/2 Inch
SKU: gtv-187304002
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model no. : GTV-187304002

We are a leading manufacturer of bolted bonnet gate valves in China, built to API 600 standards for reliable shutoff performance. Crafted from corrosion-resistant aluminum bronze ASTM B148 C95800, these valves are ideal for demanding marine and industrial applications. Available in 2-1/2 inch size with a Class 150 LB pressure rating, they feature a durable bolted bonnet design for easy maintenance and long service life. Operators can choose between handwheel or gear operation, and the valves are offered with flat face (FF) or raised face (RF) flanged ends for flexible pipeline integration.

Request a quote

Tags:

API 600 Gate Valve

Bolted Bonnet Gate Valve

Al-bronze Gate Valve

Detail Information

Valve Description:
187304002 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 2-1/2 Inch
Nominal Class: Class 150 LB, Class 300 LB
Bore Type: Standard Bore(API 600)
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Handwheel/Gear/Motor

Next: ASTM B148 C95800 Gate Valve, API 600, 3 Inches, 150 LB, RF

Previous: Aluminum Bronze Gate Valves, API 600, C95800, 2 Inch, CL150
