API 602 Piston Check Valve, F316, 3/4 Inch, 800 LB, SW, NPT

Home/Products/API 602 Forged Valves/API 602 Piston Check Valve, F316, 3/4 Inch, 800 LB, SW, NPT

Key Specifications / Features

Model No. : 0.75P8SF31612

Discover high-quality API 602 Piston Check Valves from our factory. Available in 3/4 Inch (DN20) size, rated at 800 LB (PN130), crafted from ASTM A182 F316 material with Trim 12 configuration, meeting ASME B16.34 standards. These valves feature a bolted bonnet and offer swing-type options. Suitable for SW and NPT end connections.

Request a quote

Tags:

3/4 Inch Check Valve

Class 800 LB Check Valve

ASTM A182 F316 Check Valve

Detail Information

API 602 Piston Check Valve, 3/4 INCH, 800 LB, SW/NPT, F316 Body, Trim 12

Valve Description:
1853009 API 602 Forged Piston Check Valve 0.75P8SF31612
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet
Nominal size: 3/4 Inch
Nominal class: 800 LB
Bore: Regular Bore
End Connection: SW or NPT
Operation: /
Body Material: ASTM A182 F316
Trim Material: F316+STL, No.12
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Fully guided solid disc, Piston Type (Swing type available), Low breaking pressure

Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: Class 800-2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +400℃
Operation: /
