Key Specifications / Features
Model No. : 3S9RF51
Explore high-quality swing check valves from a trusted manufacturer. Our 3-inch valves, rated at 900 LB (pound), feature DN80 and PN150 specifications, conforming to BS 1868, API 594, and API 602 standards. Crafted with an ASTM A182 F51 body, bolted bonnet, swing disc, and renewable seat, these valves ensure reliable performance. Perfect for a range of applications, our valves guarantee efficiency and durability. Choose excellence with our precision-engineered swing check valves.
Categories
Swing Check Valve
Tags:
API 602 Check Valve
, 3 Inch Check Valve
, Class 900 LB Check Valve
.
API 602 Swing Check Valve, 3 Inch, 900 lb, RF, A182 F51 body
Valve Description:
1841016 Swing Check Valve 3S9RF51
Design Standard: BS 1868, API 594, API 602
Structure: Bolted Bonnet, Swing type
Nominal size: 3 Inch
Nominal class: 900 LB
Bore Type: Reduced Bore
End Connection: RF (Raised Face)
Operation: /
Body Material: ASTM A182 F51
Trim Material: ASTM A182 F51
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Swing Disc, Renewable Seat
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 2 Inch (DN15 - DN50)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW, SW, NPT
Working temperature: -29℃ - +500℃
Operation: /
