API 609 Double Offset Butterfly Valve, A890 5A, 300 LB, 26IN

Key Specifications / Features

Model No. : 1862319
As a wafer butterfly valve manufacturer, we produce valves designed to meet EN 593 and API 609 Category B standards. Our 26-inch (DN650) double-offset butterfly valves are crafted from ASTM A890 5A duplex stainless steel for superior strength and corrosion resistance. Featuring an RPTFE seat and a robust Monel K500 stem, these valves are rated at 300 LB, ensuring reliable performance in high-pressure applications. Ideal for critical isolation and control, they provide durability and precision across various industries requiring efficient and long-lasting valve solutions.

Detail Information

High-Performance Butterfly Valve, 26 Inch/DN650, 300 LB, Double Offset, Gear Operation.

Valve Description

1862319 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Structure: Double Offset, Double Eccentric
Nominal Size: 26 Inch, DN650
Nominal Class: Class 300 LB, PN50
Seat Type: Soft Seat
Operation: Gear
Body Material: ASTM A890 5A, ASTM B148 C95800, ASTM A890 4A, Titanium, ASTM A351 CF8, ASTM A351 CF8M, ASTM A216 WCB.
Seat: RPTFE, PPL
End Connection: Wafer
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A890 4A, ASTM A890 5A, ASTM A351 CF8, ASTM A351 CF8M, ASTM B148 C95800, Titanium
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2-48 Inch (DN15-DN1200)
Pressure Range: Class 150-300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Top Mounting: ISO 5211 Top Mounting Available
