Key Specifications / Features
Model No. : 3BST1RF904L-P
Explore top-quality 3-way ball valve with ASTM A182 F904L, UNS N08904 body and trim. This 3-inch valve, DN80 size, is designed for 150 LB, PN20 pressure ratings, compliant with API 6D standards. Featuring a PEEK seat, pneumatically actuated, and equipped with DBB functionality. RF flanged end ensures secure installation for optimal performance.
Categories
Trunnion Mounted Ball Valve
Tags:
3 Inch Ball Valve
, Class 150 LB Ball Valve
, API 6D Ball Valve
.
3 Way Ball Valve, API 6D, DN80, PN16, RF, F904L (N08904) Body and Trim, PEEK Seat, Pneumactic Actuated
Valve Description:
1811055 Trunnion Mounted Ball Valve 3BST1RF904L-P
Design Standard: API 6D
Structure: Three pieces body, Side Entry, Bolted Bonnet, DBB, 3-Way
Nominal size: 3 Inch
Nominal class: 150 LB
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Pneumatic Actuator
Body Material: ASTM A182 F904L
Trim Material: ASTM A182 F904L, PEEK
Face to face: Manufacturer Standard
Test and inspection: API 598, API 6D
Key Features: DBB, Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW, HUB
Working temperature: -46℃ - +150℃
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
