ASTM A216 WCB Butterfly Valve, 48 Inch, 150 LB, API 609

Key Specifications / Features

Introducing our premium metal seat butterfly valve, expertly crafted by a trusted manufacturer. This valve boasts a generous size of 48 inches and is designed to meet the rigorous standards of Class 150 LB. Compliant with API 609 Cat B and EN 593 regulations, this valve is engineered for superior performance. With a DN1200 size and PN20 pressure rating, it offers reliability and durability in demanding applications. The valve is constructed from ASTM A216 WCB material, ensuring excellent strength and corrosion resistance. Equipped with a CR13 overlay seat, it guarantees optimal sealing capabilities. Featuring a gear operation mechanism and BW end connection, this butterfly valve is a versatile choice for various industrial applications. Trust in its precision engineering and enjoy seamless operation in your systems.

Categories Triple Offset Butterfly Valve

Tags: ASTM A216 WCB Butterfly Valve , 48 Inch Butterfly Valve , Class 150 LB Butterfly Valve .

Detail Information
48 inch (DN1200) Triple Offset Butterfly Valve, Metal Seat, API 609, EN 593, 48 Inch, 150 LB, BW, WCB body, CF8M Disc, SS+Graphite Sealing Ring, CR13 Overlay Seat, Gear Operation

Valve Description:
1863006 Triple Offset Butterfly Valve 48TC1RWCB
Design Standard: API 609 Cat B, EN 593
Structure: Triple Offset
Nominal size: 48 Inch
Nominal class: 150 LB
End Connection: BW End
Operation: Gear
Body Material: ASTM A216 WCB
Trim Material: A351 CF8M disc, Laminated Sealing ring SS 316+Graphite
Face to face: API 609
Test and inspection: API 598
Key Features: Metal Seat for high Temperature and various fluids, Low torque, Replaceable seat, Zero Leakage, Excellent control characteristics, Fire Safe

Product Range:
Body material: WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 72 Inch (DN50 - DN1800)
Pressure range: Class 150 - 2500 LB
End connection: Wafer, Lug, Flanged, BW
Working temperature: -29℃ - +400℃
Operation: Lever, Gear, Motor, Pneumatic Actuated
