Key Specifications / Features
Our API 600 carbon steel gate valve features a durable ASTM A216 WCB body, bolted bonnet, and flexible wedge design to ensure reliable shutoff performance in demanding industrial applications. This 2-inch, Class 150 LB valve is equipped with RF flanged ends for secure pipeline connection and an OS&Y configuration for clear stem position indication. The non-rising handwheel provides smooth manual operation while maintaining a compact profile, making it ideal for space-constrained installations. Engineered for long service life and consistent sealing, this valve is suitable for oil, gas, petrochemical, and general industrial systems. As a leading carbon steel gate valve factory in China, we deliver high-quality, reliable valve solutions worldwide.
Valve Description:
1821159 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Sizes: 2 Inch, DN50, 50 mm
Pressure Rating: 150 LB
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM A216 WCB, ASTM A216 WCC, ASTM A352 LCB, ASTM A352 LCC, ASTM A351 CF3, ASTM A351 CF3M, ASTM A351 CF8, ASTM A351 CF8M, ASTM A995 4A, ASTM A995 5A, 6A, ASTM B148 C95800, ASTM A217 C5, ASTM A217 WC6, WC9, C12A
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 2 - 64 Inch (DN50 - DN1600)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
