Key Specifications / Features

Model No. : 12S6RCF8C

ASTM A351 CF8C swing type check valve manufacturer offering 12-inch size, Class 600 LB, API 594 compliant, DN300, PN100, and BS 1868 standards. Features include bolted bonnet, RF end connection, available in sizes ranging from 2 to 32 inches, suitable for pressure ratings from 150 to 2500 LB.


Detail Information

12 Inch/DN300 Swing Check Valve, 600 LB, Flanged RF, BS 1868, CF8C

Valve Description:
1841014 Swing Check Valve 12S6RCF8C
Design Standard: BS 1868, API 594
Structure: Bolted Bonnet, Swing type
Nominal size: 12 Inch
Nominal class: 600 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: /
Body Material: ASTM A351 CF8C
Trim Material: ASTM A351 CF8C
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Swing Disc, Renewable Seat

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 32 Inch (DN50 - DN800)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +400℃
Operation: /
