ASTM A351 CF8M Lug Butterfly Valve, Double Offset, API 609

Key Specifications / Features
Model No. : 16TB1LWCB

Looking for a top-quality high-performance butterfly valve? Check out our Lug Type of Stainless Steel Double Offset Butterfly Valve with API 609 certification. This valve is 16 inches in size with a 150 LB rating and features a lug design, as well as a durable CF8M body and disc. The valve also includes an RPTFE seat for optimal performance. Trust us for all your industrial valve needs!

Categories Double Offset Butterfly Valve

Tags: Lug Butterfly Valve , ASTM A351 CF8M Butterfly Valve , Double Offset Butterfly Valves .

Detail Information
Lug Type Stainless Steel High-Performance Butterfly Valve, Double Offset, API 609, 16 Inch, 150 LB, Lug, CF8M body, CF8M Disc, RPTFE seat

Valve Description:
1862005 Double Offset Butterfly Valve 16TB1LWCB
Design Standard: API 609 Cat B
Structure: Double Offset
Nominal size: 16 Inch
Nominal class: 150 LB
End Connection: Lug-RF
Operation: Bare Stem, ISO 5211 Mounting
Body Material: ASTM A351 CF8M
Trim Material: A351 CF8M disc, RPTFE seat
Face to face: API 609
Test and inspection: API 598
Key Features: Long working life for frequent open/close (million cyclings), Low torque, Replaceable seat, Tight sealing, Excellent control characteristics, Standard ISO 5211 Mounting

Product Range:
Body material: WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 48 Inch (DN50 - DN800)
Pressure range: Class 150 - 300 LB
End connection: Wafer, Lug, Flanged
Working temperature: -29℃ - +120℃
Operation: Lever, Gear

High Performance Butterfly Valve Tech Drawing
