Key Specifications / Features
Model No. : 6GT25JLCB05
ASTM A352 LCB slab gate valve, manufactured by a reputable maker, is designed with a 6-inch size, suitable for Class 2500 LB applications. It complies with API 6D standards and has a DN150 (6-inch) nominal diameter and PN420 pressure rating. The valve features flanged RTJ ends, a bolted bonnet, Trim 5 internals, and an OS & Y (Outside Screw and Yoke) design. It is equipped with gear operation for easy control and operation. Choose this high-quality gate valve for reliable performance in demanding industrial environments.
Categories
Gate Valves
Tags:
ASTM A352 LCB Gate Valve
, 6 Inch Gate Valve
, Slab Gate Valve
.
API 6D Slab Gate Valve, 6 Inch, 2500 LB, OS & Y, RTJ, A352 LCB Body, Trim 5, Gear Operation
Valve Description:
1821016 Slab Gate Valve 6GT25JLCB05
Design Standard: API 6D
Structure: Bolted Bonnet
Nominal size: 6 Inch
Nominal class: 2500 LB
Bore Type: Standard Bore
End Connection: Flanged RTJ
Operation: Gear
Body Material: ASTM A352 LCB
Trim Material: /
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Slab Gate, OS & Y, Low fugitive emission stem packing available, Renewable Seat
Product Range:
Body material: Carbon Steel, Stainless Steel
Normal diameter: 2 - 48 Inch (DN50 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +350℃
Operation: Handwheel, Gear, Motor Actuator
