BS 1873 Al-bronze Globe Valve, C95800, 30 IN, CL300, PSB, FF

Name: BS 1873 Al-bronze Globe Valve, C95800, 30 IN, CL300, PSB, FF
SKU: glv-187305037
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model No. : GLV-187305037

As a leading Al-bronze Globe Valve Plant in China, we manufacture 30-inch globe valves to BS 1873 and API 623 standards. Featuring a robust aluminum bronze body and trim made from ASTM B148 C95800, these valves deliver exceptional corrosion resistance in demanding environments. Rated Class 300 LB, they include a pressure seal bonnet to ensure dependable sealing under high pressure. With options for flat face (FF) or raised face (RF) flanged ends, these valves offer versatile installation. Operated by handwheel or gear, they provide accurate flow control for marine, industrial, and offshore applications.

Request a quote

Tags:

BS 1873 Globe Valve

Al-bronze Globe Valve

ASTM B148 C95800 Globe Valve

Detail Information

Valve Description:
187305037 Aluminum Bronze Globe Valve
Design Standard: BS 1873, API 623
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 30 Inch
Nominal Class: 300 LB
Bore Type: Standard Bore
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: Features an OS&Y (Outside Screw & Yoke) design for easy maintenance and stem position visibility, along with a screwed-in back seat and rising stem for reliable sealing. The non-rising handwheel allows for space-saving operation, while the flexible wedge ensures tight shutoff and thermal flexibility. Engineered with a low emission design to reduce fugitive emissions. Constructed from corrosion-resistant aluminum bronze, this valve is ideal fo

Product Range:
Body Material: Al-bronze
Normal Diameter: 2 Inch - 24 Inch (DN50 - DN600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF/FF
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
