Carbon Steel Gate Valve, A352 LCB, 2-1/2 IN, ANSI 300, OS&Y

Key Specifications / Features

Model No. : 1821065

As a leading manufacturer of ASTM A352 LCB gate valves in China, we deliver high-quality, durable solutions for various applications. Our 2-1/2 inch (DN65) gate valve features a robust carbon steel construction and adheres to API 600 standards. With an ANSI 300 rating, it offers reliable performance under high-pressure conditions. The valve design includes an OS&Y mechanism, flexible wedge, and a pressure seal bonnet, all with raised face (RF) flanged ends for secure connections. Choose us for top-grade gate valves engineered to meet your precise specifications and industry standards.

Detail Information

2-1/2 Inch Gate Valve, ASTM A352 LCB, API 600, DN65, Class 300 LB, OS&Y, RF Flanged.

Valve Description

1821065 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A352 LCB, ASTM A351 CF8M, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800.
Nominal Size: 2-1/2 Inch, DN65
Nominal Class: CL 300 LB, PN50
End Connection: RF Flanged
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55.
Face to Face: ASME B16.10
Bore Type: Standard Bore(API 600)
Test and Inspection: API 598

Key Features

1. OS&Y (Outside Screw and Yoke) design for reliable operation.
2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
End Connections: RF, RTJ, BW
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
