Key Specifications / Features
The API 600 Gate Valve features an OS&Y configuration, ASTM A216 WCC carbon steel body, 20-inch (DN500) size, Class 1500 LB, PN250 pressure rating, pressure seal bonnet, and RTJ flanged ends for demanding high-pressure applications. Engineered for dependable shut-off performance, long service life, and operational safety, it is widely used in oil and gas, petrochemical, refinery, and power generation industries. As a leading ASTM A216 WCC Gate Valve supplier in China, we deliver premium-quality valves manufactured to international standards for reliable industrial performance worldwide.
Valve Description:
1821254 Cast Steel Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Sizes: 20 Inch, DN500
Pressure Rating: Class 1500 LB, PN250
Bore Type: Standard Bore(API 600)
End Connection: RTJ Flanged
Operation: Handwheel/Gear
Face to face: ASME B16.10
Test and inspection: API 598
Body Material: ASTM A216 WCC, ASTM A217 WC6, ASTM A995 6A, ASTM A217 WC9, ASTM A351 CF8, ASTM B148 C95800, ASTM A217 C12A, ASTM A351 CF3M, ASTM A351 CF3, ASTM A351 CF8M, ASTM A352 LCB, ASTM A352 LCC, ASTM A217 C5, ASTM A995 4A, ASTM A995 5A, ASTM A216 WCB
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure range: 150 LB - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
