Flexible Wedge Gate Valve, 10 IN, CL300, B148 C95800, OS&Y

Key Specifications / Features

Model No. : 1821070

As a leading manufacturer of ASTM B148 C95800 gate valves in China, we provide high-quality solutions for various industrial applications. Our 10-inch (DN250) gate valve features a durable aluminum bronze construction, complying with API 600 standards. Designed with a flexible wedge and OS&Y mechanism, it ensures reliable performance. With an ANSI 300 rating and a pressure seal bonnet (PSB), this valve is built for demanding environments. The raised face (RF) flanged ends offer secure connections, making it an excellent choice for high-performance needs.

Detail Information

ASTM B148 C95800 OS&Y Gate Valve, 10 Inch/DN250, API 600, Class 300 LB, Flexible Wedge, RF Flanged.

Valve Description

1821070 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A351 CF8M, ASTM A352 LCB, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800.
Nominal Size: 10 Inch, DN250
Nominal Class: CL 300 LB, PN50
Bore Type: Standard Bore(API 600)
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F53, ASTM A182 F55.
End Connection: RF Flanged
Face to Face: ASME B16.10
Test and Inspection: API 598

Key Features

1. OS&Y (Outside Screw and Yoke) design for reliable operation.
2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze.
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
End Connections: RF, RTJ, BW
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
