Key Specifications / Features
Model No. : 10GLP15BWCB16
We Provide Pressure Seal Globe Valves, Pressure Seal Bonnet (PSB), BS 1873, 10 Inch, 1500 LB, ASTM A216 WCB, Plug Disc, T type, Connival Disc, BW Ends, and Gear.
Pressure Seal Globe Valve, WCB, BS 1873, 10 IN, 1500 LB, BW
Detail Information
Product Item: Pressure Seal Globe Valve
Model No.: 10GLP15BWCB16
Design Standard: BS 1873
Structure: Pressure Seal Bonnet, T type, Plug Disc
Nominal size: 10 Inch
Nominal class: 1500 LB
Bore Type: Standard Bore
End Connection: BW (Butt Weld)
Operation: Gear
Body Material: ASTM A216 WCB
Trim Material: 316+STL, No.16
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Plug Disc, OS&Y, Rising Handwheel, Low fugitive emission stem packing available, Renewable Seat, Connival Disc available
Product Range
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 24 Inch (DN50 - DN1200)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +400℃
Operation: Handwheel, Gear, Motor Actuator
Model No.: 10GLP15BWCB16
Design Standard: BS 1873
Structure: Pressure Seal Bonnet, T type, Plug Disc
Nominal size: 10 Inch
Nominal class: 1500 LB
Bore Type: Standard Bore
End Connection: BW (Butt Weld)
Operation: Gear
Body Material: ASTM A216 WCB
Trim Material: 316+STL, No.16
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Plug Disc, OS&Y, Rising Handwheel, Low fugitive emission stem packing available, Renewable Seat, Connival Disc available
Product Range
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 24 Inch (DN50 - DN1200)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +400℃
Operation: Handwheel, Gear, Motor Actuator
Next: ASTM A351 CF8C Pressure Seal Globe Valve, 10 Inch, 2500 LB
Previous: BS 1873 Globe Valve, Bolted Bonnet, 4 Inch, 150 LB, RF, WCB
