Rising Stem Gate Valve, API 600, CF3M, 28 IN, CL300, OS&Y

Name: Rising Stem Gate Valve, API 600, CF3M, 28 IN, CL300, OS&Y
SKU: 1821194
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model No. : 1821194

Our Cast Steel Gate Valve is manufactured to API 600 standards for reliable isolation service in demanding industrial pipeline systems. Constructed from ASTM A351 CF3M stainless steel, it offers excellent corrosion resistance, durability, and dependable performance in harsh operating environments. Available in 28 inch size, DN700, with a Class 300 LB pressure rating, this valve features a bolted bonnet design for secure sealing and easier maintenance. RF flanged ends ensure convenient installation and leak-tight connections. Ideal for water, chemical, oil, gas, and process industries. As a leading Rising Stem Gate Valve Supplier in China, we deliver trusted quality.

Request a quote

Tags:

Rising Stem Gate Valve

API 600 Gate Valve

ASTM A351 CF3M Gate Valve

Detail Information

Valve Description:
1821194 Cast Steel Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Sizes: 28 Inches, DN700
Pressure Rating: Class 300 LB
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM A351 CF3M, ASTM A351 CF3, ASTM A216 WCC, ASTM A217 WC6, ASTM A995 6A, ASTM A217 WC9, ASTM A351 CF8, ASTM A217 C12A, ASTM B148 C95800, ASTM A995 5A, ASTM A351 CF8M, ASTM A216 WCB, ASTM A352 LCB, ASTM A352 LCC, ASTM A995 4A, ASTM A217 C5
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure range: 150 LB - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
