Key Specifications / Features
As a leading Rising Stem Gate Valves factory in China, we manufacture this API 600 gate valve with a rugged ASTM A351 CF8 stainless steel body. Designed for heavy-duty service, this 10-inch (DN250) valve features Class 150 LB pressure rating and raised face (RF) flanged ends for secure pipeline connection. Equipped with a bolted bonnet, OS&Y structure, and screwed-in back seat, it ensures reliable sealing, easy operation, and long service life. Ideal for oil, gas, water, and industrial processing systems.
Valve Description:
1821165 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Sizes: 10 Inches, DN250, 250 mm
Pressure Rating: 150 LB, PN20
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM A351 CF8, ASTM A351 CF3, ASTM A352 LCB, ASTM A216 WCB, ASTM A216 WCC, ASTM A352 LCC, ASTM A351 CF3M, ASTM A351 CF8M, ASTM A995 4A, ASTM A995 5A, 6A, ASTM B148 C95800, ASTM A217 C5, ASTM A217 WC6, WC9, C12A
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
