Titanium Alloy Flanged Butterfly Valve, CL300, 26 IN, API 609

Key Specifications / Features

Model No. : 1862403
As a premier manufacturer of flanged butterfly valves, we provide high-quality solutions that meet API 609 Category B standards. Our 26-inch valves, crafted from durable titanium alloy, feature a soft RPTFE seat and a robust Monel K500 stem for excellent sealing performance. Designed with a double offset configuration and rated for 300 LB, these valves ensure reliable operation in demanding applications. With their lightweight yet strong construction, they offer superior resistance to corrosion and wear, making them ideal for various industrial environments requiring efficiency and longevity.

Detail Information

API 609 Butterfly Valve, Titanium Alloy Body, 26 Inch, 300 LB, RPTFE Seated.

Valve Description

1862403 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Body Material: Titanium Alloy, ASTM A890 4A, ASTM B148 C95800, ASTM A216 WCB, ASTM A890 5A, ASTM A351 CF8M, ASTM A351 CF8.
Nominal Size: 26 Inch
Nominal Class: Class 300 LB, PN50
Structure: Double Offset, Double Eccentric
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Double Flanged
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Normal Diameter: 1/2-48 Inch (DN15-DN1200)
Pressure Range: Class 150 - 300 LB
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged
Bosseal Valve advantages: 0 Leakage, low Torque, Long working life, Low Emission, Bi-direction and Fire Safe Design.
