Key Specifications / Features
Model No. : 10BS6RLF2
Explore top-quality trunnion-mounted ball Valves from a leading manufacturer. Our 10-inch valve, designed for Class 600 LB (PN100), complies with API 6D standards and is constructed with ASTM A350 LF2 material. Featuring F316 Trim, PEEK Seat, and RF Flanged End, this full-bore valve is equipped with gear operation for efficient use. Trust in our precision engineering for reliable performance in diverse industrial applications.
Categories
Trunnion Mounted Ball Valve
Tags:
Class 600 LB Ball Valve
, ASTM A350 LF2 Ball Valve
, API 6D Ball Valve
.
Trunnion Mounted Ball Valve, API 6D, 10 inch, 600 LB, RF, LF2 Body, F316 Trim, PEEK Seat, Gear Operation
Valve Description:
1811053 Trunnion Mounted Ball Valve 10BS6RLF2
Design Standard: API 6D
Structure: Three pieces body, Side Entry, Bolted Bonnet, DBB
Nominal size: 10 Inch
Nominal class: 600 LB
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Gear
Body Material: ASTM A350 LF2
Trim Material: ASTM A182 F316, PEEK
Face to face: ASME B16.10
Test and inspection: API 598, API 6D
Key Features: DBB, Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW, HUB
Working temperature: -46℃ - +150℃
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
