Al-bronze Wedge Gate Valve, API 600, PSB, OS&Y, 30 IN, CL300

Key Specifications / Features

Model no. : GTV-187304037

As a leading aluminum bronze gate valve provider in China, we offer premium solutions designed to API 600 standards. Our 30-inch, Class 300 LB gate valves are built with a pressure seal bonnet for enhanced strength and reliability under high pressure. Featuring an OS&Y configuration and a flexible wedge design, these valves ensure smooth operation and tight shutoff. Engineered with a low emission design, they help meet strict environmental regulations. Constructed from durable aluminum bronze, they are ideal for corrosive environments such as marine, offshore, and chemical processing applications.


Detail Information

Valve Description:
187304037 Aluminum Bronze Gate Valve, OS&Y, Flexible Wedge.
Design Standard: API 600
Nominal Size: 30 Inch
Nominal Class: Class 300 LB
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Bore Type: Standard Bore(API 600)
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Structure: Bolted Bonnet/Pressure Seal Bonnet
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2-64 Inch (DN50 - DN1600)
Pressure Range: 150-300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Handwheel/Gear/Motor
