2-1/2 Inch Gate Valve, API 600, Al-bronze, B148 C95800, RF

Key Specifications / Features

Model no. : GTV-187304023

We are a China-based manufacturer of high-quality gate valves designed to API 600 standards. Built with a corrosion-resistant aluminum bronze ASTM B148 C95800 body and trim, these valves are ideal for demanding marine and industrial applications. Available in a 2-1/2 inch size with a Class 300 LB pressure rating, they feature a bolted bonnet for secure sealing and an outside screw and yoke (OS&Y) design for straightforward operation and maintenance. Offered with flat face (FF) or raised face (RF) flanged ends, these valves provide reliable, long-lasting performance in harsh environments.


Detail Information

Valve Description:
187304023 Aluminum Bronze Gate Valve.
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 2-1/2 Inch
Nominal Class: Class 300 LB
Bore Type: Standard Bore(API 600)
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Handwheel/Gear/Motor
