Key Specifications / Features
Model No. : 3GA25NF321
Explore our premium Angle Globe Valve, crafted to perfection with specifications including DN80 size, PN320 pressure rating, BS 1873 standard, 3-inch dimension, ASTM A182 F321 material, Pressure Seal Bonnet, Plug Disc, and equipped with a Gear Box. Ideal for Power Generation and High-Temperature applications.
Categories
Globe Valves
Tags:
DN80 Globe Valve
, ASTM A182 F321 Globe Valve
, BS 1873 Globe Valve
.
Angle Globe Valve, DN80, PN320, NPT, F321 Material, Gear Box
Valve Description:
1831013 Globe Valve 3GA25NF321
Design Standard: BS 1873
Structure: Pressure Seal Bonnet, Plug Disc, ANGLE TYPE
Nominal size: DN80
Nominal class: PN320
Bore Type: Standard Bore
End Connection: NPT
Operation: Gear
Body Material: ASTM A182 F321
Trim Material: ASTM A182 F321
Face to face: MFG'S
Test and inspection: API 598
Key Features: Plug Disc, OS & Y, Rising Handwheel, Low fugitive emission stem packing available, Renewable Seat, Connival Disc available, for power generation and high temperature
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 24 Inch (DN50 - DN1200)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW, NPT
Working temperature: -29℃ - +500℃
Operation: Handwheel, Gear, Motor Actuator
