Key Specifications / Features
Model No. : 3GLP15BWCB05
Explore top-quality Pressure Seal Bonnet Globe Valves from a reliable supplier. Our 3-inch valves, rated at 1500 LB, conform to BS 1873 standards with a Plug Disc design. Crafted from ASTM A216 WCB material and Trim 5 specifications, these valves boast durability and efficiency. The valves feature DN80 and PN250, ensuring robust performance. With ASTM A182 F6A+STL.6 Trim and Connival Disc options, these valves are a preferred choice. Available in Butt Weld (BW) configuration, trust us for excellence in valve solutions.
Categories
Globe Valves
Tags:
3 Inch Globe Valve
, Class 1500 LB Globe Valve
, ASTM A216 WCB Globe Valve
.
Pressure Seal Globe Valve, 3 inch, 1500 LB, BW, WCB body, trim 5, BS 1873, Handwheel
Valve Description:
1831011 Globe Valve 3GLP15BWCB05
Design Standard: BS 1873
Structure: Pressure Seal Bonnet, Plug Disc
Nominal size: 3 Inch
Nominal class: 1500 LB
Bore Type: Standard Bore
End Connection: BW
Operation: Handwheel
Body Material: ASTM A216 WCB
Trim Material: A182 F6A+STL.6
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Plug Disc, OS & Y, Rising Handwheel, Low fugitive emission stem packing available, Renewable Seat, Connival Disc available
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 24 Inch (DN50 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +400℃
Operation: Handwheel, Gear, Motor Actuator
