API 600 Gate Valve, 2 Inch, 150 LB, ASTM A216 WCB, RF Flanged

Name: API 600 Gate Valve, 2 Inch, 150 LB, ASTM A216 WCB, RF Flanged
SKU: 1821043
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model No. : 1821043

As a leading 2-inch gate valve manufacturer from China, we offer high-quality valves designed to API 600 standards. Our valve is crafted from durable carbon steel ASTM A216 WCB, ensuring robust performance and longevity. With a Class 150 LB rating and DN50 size, it features a bolted bonnet and a screwed-in back seat for enhanced security. The valve operates with an OS&Y (Outside Screw and Yoke) design, rising stem, and non-rising handwheel, complemented by a flexible wedge for superior sealing. It also incorporates a low emission design, making it suitable for various industrial applications.

Request a quote

Tags:

API 600 Gate Valve

2 Inch Gate Valve

Class 150 LB Gate Valve

Detail Information

ASTM A216 WCB Gate Valve, API 600, 2 Inch/DN50, 150 LB, Handwheel/Gear Operation.

Valve Description

1821043 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800.
Nominal Size: 2 Inch, DN50
Nominal Class: 150 LB, PN10
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55.
Face to Face: ASME B16.10
Test and Inspection: API 598

Key Features

1. OS&Y (Outside Screw and Yoke) design.
2. Screwed-in back seat for added security.
3. Rising stem with the non-rising handwheel.
4. Flexible wedge for improved sealing.
5. Low emission design for environmental compliance.

Product Range

Body Material:	Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze
Normal Diameter:	2 - 64 Inch (DN50 - DN1600)
Pressure Range:	150 - 2500 LB
End Connections:	RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld)
Working Temperature:	-29°C - +400°C
Operation:	Handwheel/Gear/Motor

Pressure Seal Bonnet Gate Valve

Drawing for Gate Valve

Next: ASTM A352 LCB Gate Valve, 2-1/2 IN, 150 LB, Bolted Bonnet

Previous: ASTM A536 Resilient Gate Valve, DN1200, PN16, DIN 3352
