API 6D Check Valves, Aluminum Bronze C95800, 6 IN, CL300 LB

Name: API 6D Check Valves, Aluminum Bronze C95800, 6 IN, CL300 LB
SKU: ckv-187306026
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model No. : CKV-187306026

As a trusted aluminum bronze check valve supplier, we offer high-quality check valves designed to API 6D, API 594, and BS 1868 standards for dependable backflow prevention. Each valve is built with a durable body and trim made from aluminum bronze ASTM B148 C95800, providing superior corrosion resistance and long service life in harsh environments. Available in a 6-inch size with a Class 300 LB pressure rating, these valves feature a bolted bonnet for secure sealing and easy maintenance, along with flat face (FF) or raised face (RF) flanged ends for versatile installation.

Request a quote

Tags:

API 6D Check Valve

Aluminum bronze Check Valve

ASTM B148 C95800 Check Valve

Detail Information

Valve Description:
187306026 Aluminum Bronze Check Valve, Swing Check Valve
Design Standard: API 6D, BS 1868, API 594
Structure: Bolted Bonnet
Nominal Size: 6 Inch
Nominal Class: 300 LB
Bore Type: Full Bore(API 6D) or Standard Bore(BS 1868, API 594)
End Connection: FF or RF Flanged
Operation: NA
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: Bolted Bonnet, Full Opening design available, Operation Lever design Available, Aluminium Bronze for Sea Water Service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Not Applicable (Manual or actuated available for special request)
