ASTM B148 C95800 Swing Check Valve, 12 IN, CL300, RF Flanged

Name: ASTM B148 C95800 Swing Check Valve, 12 IN, CL300, RF Flanged
SKU: ckv-187306029
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model No. : CKV-187306029

As a leading swing check valve manufacturer from China, we produce high-quality valves designed to API 6D, API 594, and BS 1868 standards, ensuring reliable backflow prevention and smooth operation. Each valve features a durable body and trim made from aluminum bronze ASTM B148 C95800, offering excellent corrosion resistance and long-lasting performance. Available in a 12-inch size with a Class 300 LB pressure rating, these valves come with bolted bonnets for secure sealing and easy maintenance. They are supplied with flat face (FF) or raised face (RF) flanged ends, suitable for demanding marine and industrial applications.

Request a quote

Tags:

ASTM B148 C95800 Check Valve

12 Inch Check Valve

Class 300 LB Check Valve

Detail Information

Valve Description:
187306029 Aluminum Bronze Check Valve, Swing Check Valve
Design Standard: API 6D, BS 1868, API 594
Structure: Bolted Bonnet
Nominal Size: 12 Inch
Nominal Class: 300 LB
Bore Type: Full Bore(API 6D) or Standard Bore(BS 1868, API 594)
End Connection: FF or RF Flanged
Operation: NA
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: Bolted Bonnet, Full Opening design available, Operation Lever design Available, Aluminium Bronze for Sea Water Service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Not Applicable (Manual or actuated available for special request)
