ASTM A217 C12A Gate Valve, API 600, 2 Inch, 900 LB, PSB, RTJ

Key Specifications / Features

Model No. : 1821222

Featuring a pressure seal bonnet design, this gate valve is manufactured from high-quality cast steel ASTM A217 C12A body with F55 trim, ensuring superior strength, corrosion resistance, and reliable performance in severe service conditions. With a 2-inch (DN50) size, Class 900 LB pressure rating, and RTJ flanged ends, it provides secure sealing and excellent durability under high-pressure and high-temperature environments. Designed to meet stringent industrial standards, it is widely used in oil, gas, and power applications. As a leading API 600 Gate Valve Factory from China, we deliver precision-engineered valves for critical industrial operations.


Detail Information

Valve Description:
1821222 Cast Steel Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Sizes: 2 Inch, DN50
Pressure Rating: Class 900 LB, PN150
Bore Type: Standard Bore(API 600)
End Connection: RTJ Flanged
Operation: Handwheel/Gear
Body Material: ASTM A217 C12A, ASTM A351 CF3M, ASTM A351 CF3, ASTM A351 CF8M, ASTM A352 LCB, ASTM A352 LCC, ASTM A217 C5, ASTM A995 4A, ASTM A216 WCC, ASTM A217 WC6, ASTM A995 6A, ASTM A217 WC9, ASTM A351 CF8, ASTM B148 C95800, ASTM A995 5A, ASTM A216 WCB
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure range: 150 LB - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
