ASTM A217 C5 Rising Stem Gate Valve, API 600, 6 IN, CL600 LB

Key Specifications / Features

Model No. : 1821205

This rising stem gate valve features a bolted bonnet design manufactured to API 600 standards, with a durable ASTM A217 C5 alloy steel body and F316 trim for excellent corrosion and heat resistance. Sized 6 inch (DN150), it is rated Class 600 LB and PN100 for demanding high-pressure service. The RF flanged ends ensure secure installation, while the OS&Y construction provides clear valve position indication and dependable stem operation. Designed for tight shutoff and long service life, it is ideal for power, petrochemical, and refinery systems. As a leading China Rising Stem Gate Valve Supplier, we provide reliable valve solutions worldwide.


Detail Information

Valve Description:
1821205 Cast Steel Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Sizes: 6 Inch, DN150
Pressure Rating: Class 600 LB, PN100
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM A217 C5, ASTM A995 4A, ASTM A217 C12A, ASTM A351 CF3M, ASTM A351 CF3, ASTM A216 WCC, ASTM A217 WC6, ASTM A995 6A, ASTM A217 WC9, ASTM A351 CF8, ASTM B148 C95800, ASTM A995 5A, ASTM A351 CF8M, ASTM A216 WCB, ASTM A352 LCB, ASTM A352 LCC
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure range: 150 LB - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
