Key Specifications / Features
These Rising Stem Gate Valves are manufactured to API 600 standards and feature a robust cast steel construction for reliable performance in high-pressure and high-temperature applications. Designed in 26-inch (DN650) size with a Class 600 LB pressure rating, the valves are equipped with RF flanged ends and a pressure seal bonnet to ensure secure sealing and operational safety. The rising stem design allows clear visual indication of valve position and smooth operation. Widely used in oil & gas, petrochemical, and power generation industries, these valves provide dependable shutoff and long service life. As a leading ASTM A995 5A Gate Valves Supplier in China, we offer premium-quality products with competitive pricing and strict quality standards.
Valve Description:
1821214 Cast Steel Gate Valve
Design Standard: API 600
Sizes: 26 Inches, DN650
Pressure Rating: Class 600 LB, PN100
Bore Type: Standard Bore(API 600)
Face to Face: ASME B16.10
End Connection: RF Flanged
Operation: Handwheel/Gear
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A995 5A, ASTM A216 WCC, ASTM A217 WC6, ASTM A995 6A, ASTM A217 WC9, ASTM A351 CF8, ASTM B148 C95800, ASTM A216 WCB, ASTM A351 CF8M, ASTM A352 LCB, ASTM A352 LCC, ASTM A217 C5, ASTM A995 4A, ASTM A217 C12A, ASTM A351 CF3, ASTM A351 CF3M
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Test and inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
