Key Specifications / Features
The 24 Inch (DN600) cast steel gate valve is manufactured in accordance with API 600 standards, featuring a bolted bonnet design for secure sealing and easy maintenance. Constructed from ASTM A217 C5 alloy steel, it provides excellent strength and resistance to high-temperature and high-pressure service conditions. Designed to Class 150 LB (PN20), the valve is equipped with an outside screw and yoke (OS&Y) structure for clear position indication and reliable operation. RF flanged ends ensure tight, leak-free connections in pipeline systems. Ideal for power generation, petrochemical, and industrial applications, it delivers dependable shut-off performance. As a leading API 600 wedge gate valve manufacturer in China, we provide robust and high-quality flow control solutions.
Valve Description:
1821171 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Sizes: 24 Inch, DN600
Pressure Rating: Class 150 LB, PN20
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM A217 C5, ASTM A995 6A, ASTM A995 4A, ASTM A351 CF8, ASTM A351 CF3, ASTM A352 LCB, ASTM A216 WCB, ASTM A216 WCC, ASTM A352 LCC, ASTM A351 CF3M, ASTM A351 CF8M, ASTM A995 5A, ASTM B148 C95800, ASTM A217 WC6, WC9, C12A
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
