Flexible Wedge Gate Valve, API 600, B148 C95800, 28 Inches

Key Specifications / Features

Model no. : GTV-187304015

We are a trusted supplier of flexible wedge gate valves in China, built to API 600 standards and crafted from corrosion-resistant aluminum bronze ASTM B148 C95800. Designed for demanding marine and industrial environments, these valves feature a 28-inch size (DN700) and are rated for Class 150 LB. The design includes an OS&Y (outside screw and yoke) configuration with a non-rising handwheel for space-saving operation and easy maintenance. RF (raised face) flanged ends ensure secure connections, making these valves ideal for high-performance, saltwater, and corrosive fluid applications.


Detail Information

Valve Description:
187304015 Aluminum Bronze Gate Valve, OS&Y, Flexible Wedge.
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Bore Type: Standard Bore(API 600)
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Nominal Size: 28 Inch, DN700
Nominal Class: Class 150 LB, Class 300 LB
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Handwheel/Gear/Motor
