ASTM A217 WC6 Gate Valve, Bolted Bonnet, 16 IN, 600 LB, OS&Y

Key Specifications / Features

Model No. : 1821210

Designed in accordance with API 600 standards, this OS&Y gate valve is manufactured from ASTM A217 WC6 body material, ensuring excellent strength and high-temperature resistance. With a size of 16 inch (DN400) and pressure rating of Class 600 LB, it features RF flanged ends and is available with handwheel or gear operation for flexible control. The bolted bonnet design enhances sealing reliability and simplifies maintenance. Engineered for demanding industrial applications, it delivers stable performance and long service life. As a leading bolted bonnet gate valve supplier in China, we provide high-quality, cost-effective valve solutions for global industries.


Detail Information

Valve Description:
1821210 Cast Steel Gate Valve
Design Standard: API 600
Sizes: 16 Inch, DN400
Pressure Rating: Class 600 LB, PN100
Bore Type: Standard Bore(API 600)
Face to Face: ASME B16.10
End Connection: RF Flanged
Operation: Handwheel/Gear
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A217 WC6, ASTM A995 6A, ASTM A217 WC9, ASTM A351 CF8, ASTM B148 C95800, ASTM A216 WCB, ASTM A995 5A, ASTM A351 CF8M, ASTM A352 LCB, ASTM A352 LCC, ASTM A217 C5, ASTM A995 4A, ASTM A217 C12A, ASTM A351 CF3, ASTM A216 WCC, ASTM A351 CF3M
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55

Test and inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
