Key Specifications / Features
Featuring a pressure seal bonnet design, this gate valve is manufactured with ASTM A352 LCB body and F6A trim for excellent strength, wear resistance, and reliable sealing performance. With a size of 14 inch (DN350) and pressure rating of Class 600 LB, it is equipped with RF flanged ends, a rising stem, and a flexible wedge for smooth operation and tight shutoff. Designed for high-pressure industrial applications, it ensures durability and long service life under demanding conditions. As a leading API 600 gate valves factory in China, we provide high-quality, cost-effective valve solutions with strict quality control standards.
Valve Description:
1821209 Cast Steel Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Sizes: 14 Inch, DN350
Pressure Rating: Class 600 LB, PN100
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM A352 LCB, ASTM A352 LCC, ASTM A217 C5, ASTM A995 4A, ASTM A217 C12A, ASTM A351 CF3M, ASTM A351 CF3, ASTM A216 WCC, ASTM A217 WC6, ASTM A995 6A, ASTM A217 WC9, ASTM A351 CF8, ASTM B148 C95800, ASTM A995 5A, ASTM A351 CF8M, ASTM A216 WCB
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure range: 150 LB - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
