ASTM A350 LF2 Floating Ball Valve, 2 Inch, 800 LB, API 608

Key Specifications / Features
Model No. : 2BB8NLF2

Discover a high-quality 2-inch Floating Ball Valve designed to API 608 standards. Crafted with a Forged A350 LF2 Body, this valve ensures durability and reliability. With an 800 LB rating and RF connection, it guarantees optimal performance. The F316 Trim and Soft Seat enhance its functionality, while the Lever Operation adds ease of use. Explore this precision-engineered valve for your industrial needs.

Categories Floating Ball Valve

Tags: ASTM A350 LF2 Ball Valve , 2 Inch Ball Valve , Class 800 LB Ball Valve .

Detail Information
Floating Ball Valve, API 608, Forged A350 LF2 Body, 2 inch, 800 LB, RF, F316 Trim, Soft Seat, Lever Operation

Valve Description:
1812014 Floating Ball Valve 2BB8NLF2
Design Standard: API 608, ISO 17292, API 6D
Structure: Two pieces body, Side Entry, Bolted Bonnet, Soft Seat, O-ring for stem and body joint
Nominal size: 2 Inch, DN50
Nominal class: 800 LB
Bore Type: Full Bore
End Connection: NPT Threaded
Operation: Lever Lockable
Body Material: ASTM A350 LF2
Trim Material: ASTM A182 F316, DEVLON
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 8 Inch (DN15 - DN200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, SW, NPT, BW
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator
