Key Specifications / Features
This API 600 gate valve features a bolted bonnet OS&Y design with a duplex ASTM A351 CF3 body and robust trim 8 components, ensuring exceptional durability and corrosion resistance. With a 24-inch (DN600) size, Class 300 LB rating, and RF flanged ends, it provides reliable performance in high-pressure industrial applications. The flexible wedge design ensures tight shut-off, smooth operation, and long service life, making it ideal for oil, gas, chemical, and water pipelines. As a leading flexible wedge gate valve supplier in China, we deliver premium, dependable valves engineered to meet rigorous industry standards.
Valve Description:
1821192 Cast Steel Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Sizes: 24 Inch, DN600
Pressure Rating: Class 300 LB, PN50
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM A351 CF3, ASTM A216 WCC, ASTM A217 WC6, ASTM A995 6A, ASTM A217 WC9, ASTM A351 CF8, ASTM A217 C12A, ASTM B148 C95800, ASTM A995 5A, ASTM A351 CF8M, ASTM A351 CF3M, ASTM A216 WCB, ASTM A352 LCB, ASTM A352 LCC, ASTM A995 4A, ASTM A217 C5
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure range: 150 LB - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
