Aluminum Bronze Gate Valves, API 600, 24 Inches, 300 LB, FF

Key Specifications / Features

Model no. : GTV-187304034

We are a trusted manufacturer of aluminum bronze gate valves designed in accordance with API 600 standards. Our valves feature a durable ASTM B148 C95800 body and trim, offering excellent corrosion resistance for demanding applications. Available in 24-inch size (DN600), these valves are rated for Class 300 LB (PN50) pressure and are offered with flat face (FF) or raised face (RF) flanged ends. Engineered for reliability and performance, our aluminum bronze gate valves are ideal for marine, offshore, and corrosive environments where long service life is essential.


Detail Information

Valve Description:
187304034 Aluminum Bronze Gate Valve, OS&Y.
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 24 Inch, DN600
Nominal Class: Class 300 LB, PN50
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Bore Type: Standard Bore(API 600)
End Connection: FF or RF Flanged
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Handwheel/Gear/Motor
