Key Specifications / Features
Model No. : 1.25BB1NCF8
Explore superior quality with our ASTM A351 CF8 Ball Valve crafted in accordance with ASME B16.34 and ISO 17292 standards. This precision-engineered valve, boasting a 1-1/4 inch size, operates at 1000 PSI and features a DN32 size, floating ball design, and threaded bonnet for optimal performance. The 304 trim ensures durability, while the NPT threaded configuration and anti-blowout stem enhance reliability. Elevate your industrial applications with this high-performance ball valve designed for excellence.
Categories
Floating Ball Valve
Tags:
ASTM A351 CF8 Ball Valve
, NPT Ball Valve
, ASME B16.34 Ball Valve
.
1-1/4 inch, 1000 PSI, Floating Ball Valve, Threaded Bonnet, NPT End, CF8 body with 304 Trim, RPTFE seat and Lever Operation
Valve Description:
1812029 Floating Ball Valve 1.25BB1NCF8
Design Standard: ASME B16.34, ISO 17292
Structure: Two pieces body, Side Entry, Bolted Bonnet, Soft Seat
Nominal size: 1-1/4 Inch
Nominal class: 1000 PSI
Bore Type: Full Bore
End Connection: NPT Threaded
Operation: Lever Operation
Body Material: ASTM A351 CF8
Trim Material: ASTM A182 F304, RPTFE
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Anti-static Device, Anti-Blowout Stem
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 2 Inch (DN15 - DN50)
Pressure range: Class 150 - 2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator
