Key Specifications / Features
Model No. : 2B1RCF8-P
Discover top-quality pneumatic actuated ball valves from our ISO 17292 certified provider. Our valves feature a floating-type design with a two-piece body constructed from ASTM A351 CF8 material. With a 2-inch size (DN50), these valves are rated for 1000 PSI pressure, equipped with A182 F304 trim and soft seat for optimal performance. The valves come with butt-weld (BW) ends, ensuring reliability and durability for a wide range of applications.
Categories
Floating Ball Valve
Tags:
Pneumatic Actuated Ball Valve
, 2 Inch Ball Valve
, 1000 PSI Ball Valve
.
Pneumatic Actuated Floating Ball Valve, ISO 17292, DN50, 1000 PSI, BW, A351 CF8 Body, F304 Trim, Soft Seat, Pneumatic Actuated
Valve Description:
1812032 Floating Ball Valve 2B1RCF8-P
Design Standard: ISO 17292
Structure: Two pieces body, Side Entry, Bolted Bonnet, Soft Seat
Nominal size: 2 Inch, DN50
Nominal class: 1000 psi
Bore Type: Full Bore
End Connection: Butt Weld
Operation: Pneumatic Operation
Body Material: ASTM A351 CF8
Trim Material: ASTM A182 F304, RPTFE/TFM 1600
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device
Product Range:
Body material: Stainless Steel
Normal diameter: 1/2 - 8 Inch (DN15 - DN200)
Pressure range: Class 150 - 300LB
End connection: RF, RTJ, SW, NPT, BW
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator
