ASTM A352 LCB Gate Valve, BB, OS&Y, 14 IN, CL300, API 600

Key Specifications / Features

Model No. : 1821072

As a leading manufacturer of pressure seal bonnet gate valves from China, we deliver robust and reliable solutions for demanding applications. Our 14-inch (DN350) gate valve, crafted from carbon steel ASTM A352 LCB, complies with API 600 standards. It features a flexible wedge and OS&Y design, ensuring dependable performance. With a 300 LB rating and raised face (RF) flanged ends, this valve is built for high-pressure conditions. Choose us for top-quality gate valves engineered to meet your specific needs and industry requirements.

Detail Information

API 600 Gate Valve, OS&Y, ASTM A352 LCB Body, 14 Inch/DN350, 300 LB, RF Flanged.

Valve Description

1821072 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A352 LCB, ASTM A351 CF8, ASTM B148 C95800, ASTM A216 WCB, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A.
Nominal Size: 14 Inch, DN350
Nominal Class: Class 300 LB, PN50
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: RF Flanged
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55
Bore Type: Standard Bore(API 600)
Operation: Handwheel/Gear

Key Features

1. OS&Y (Outside Screw and Yoke) design for reliable operation.
2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze.
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
End Connections: RF, RTJ, BW
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
