ASTM B148 C95800 Flanged Check Valve, 8 Inch, CL150 LB, FF

Name: ASTM B148 C95800 Flanged Check Valve, 8 Inch, CL150 LB, FF
SKU: ckv-187306006
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Home/Products/Check Valves/Swing Check Valve/ASTM B148 C95800 Flanged Check Valve, 8 Inch, CL150 LB, FF

Key Specifications / Features

Model No. : CKV-187306006

As a trusted China flanged check valve supplier, we offer an 8-inch (DN200) valve engineered to meet API 6D, BS 1868, and API 594 standards. Constructed with a sturdy aluminum bronze body (ASTM B148 C95800), it provides outstanding corrosion resistance. Rated for Class 150 LB and PN20, the valve features a bolted bonnet for secure sealing and easy maintenance. Perfectly suited for challenging marine, offshore, and industrial environments, this valve delivers dependable backflow prevention and durable performance, making it an ideal solution for critical fluid control applications.

Request a quote

Tags:

ASTM B148 C95800 Check Valve

Flanged Check Valve

8 Inch Check Valve

Detail Information

Valve Description:
187306006 Aluminum Bronze Check Valve, Swing Check Valve
Design Standard: API 6D, BS 1868, API 594
Structure: Bolted Bonnet
Nominal Size: 8 Inch
Nominal Class: 150 LB
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Test and Inspection: API 598
Bore Type: Full Bore(API 6D) or Standard Bore(BS 1868, API 594)
End Connection: FF or RF Flanged
Operation: NA
Face to Face: ASME B16.10

Key Features: Bolted Bonnet, Full Opening design available, Operation Lever design Available, Aluminium Bronze for Sea Water Service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Not Applicable (Manual or actuated available for special request)
