ASTM B148 C95800 Flanged Gate Valve, API 600, 3 IN, 300 LB

Key Specifications / Features

Model no. : GTV-187304024

We are a trusted flanged gate valve manufacturer in China, specializing in high-quality valves designed to API 600 standards. This 3-inch Class 300 LB gate valve is crafted from durable aluminum bronze ASTM B148 C95800, ensuring excellent corrosion resistance and long-term performance. It features a bolted bonnet construction and a screwed-in back seat for added safety and reliability in demanding applications. Engineered for precision and built to last, our gate valves are ideal for marine, offshore, and industrial environments where strength and corrosion resistance are essential.


Detail Information

Valve Description:
187304024 Aluminum Bronze Gate Valve, OS&Y, Flexible Wedge.
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 3 Inch, DN80
Nominal Class: Class 300 LB, PN50
Bore Type: Standard Bore(API 600)
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Handwheel/Gear/Motor
