ASTM B148 C95800 Globe Valve, 40 Inch, CL300 LB, OS&Y, RF

Key Specifications / Features

Model No. : GLV-187305040

As a trusted ASTM B148 C95800 Globe Valve Factory in China, we manufacture large-size globe valves designed to BS 1873 and API 623 standards. With a durable aluminum bronze body and OS&Y configuration, our 40-inch valves offer superior corrosion resistance and reliable flow control in demanding environments. Rated for Class 300 LB, they feature raised face (RF) flanged ends and are equipped with gear operation for smooth and precise handling. Ideal for marine, offshore, and industrial applications requiring robust performance and long service life.

Detail Information

Valve Description:
187305040 Aluminum Bronze Globe Valve
Design Standard: BS 1873, API 623
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 40 Inch
Nominal Class: 300 LB
Bore Type: Standard Bore
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 24 Inch (DN50 - DN600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF/FF
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
