Aluminum Bronze Check Valves, API 6D, BS 1868, API 594, 14 IN

Name: Aluminum Bronze Check Valves, API 6D, BS 1868, API 594, 14 IN
SKU: ckv-187306030
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model No. : CKV-187306030

As a leading aluminum bronze check valve supplier in China, we offer valves designed to API 6D, API 594, and BS 1868 standards for reliable and efficient backflow prevention. Crafted from high-quality aluminum bronze ASTM B148 C95800, these valves provide excellent corrosion resistance and durability. Available in a 14-inch size with a Class 300 LB pressure rating, they feature a bolted bonnet for secure sealing and easy maintenance. Supplied with either flat face (FF) or raised face (RF) flanged ends, these check valves are ideal for demanding marine and industrial applications.

Request a quote

Tags:

Aluminum bronze Check Valve

API 6D Check Valve

BS 1868 Check Valve

Detail Information

Valve Description:
187306030 Aluminum Bronze Check Valve, Swing Check Valve
Design Standard: API 6D, BS 1868, API 594
Structure: Bolted Bonnet
Nominal Size: 14 Inch
Nominal Class: 300 LB
Bore Type: Full Bore(API 6D) or Standard Bore(BS 1868, API 594)
End Connection: FF or RF Flanged
Operation: NA
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: Bolted Bonnet, Full Opening design available, Operation Lever design Available, Aluminium Bronze for Sea Water Service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Not Applicable (Manual or actuated available for special request)
