Key Specifications / Features
Model No. : 6BS6RWCB-DIB1
Looking for a high-quality steel trunnion-mounted ball valve for your API operation? Check out the DIB-1 Casting Steel Trunnion Mounted Ball Valve with API 6D certification. This 6-inch valve can withstand 600 LB pressures and features an RF design for secure installation. The WCB body and F6A trim to make it durable and long-lasting, while the PEEK seat provides excellent resistance to corrosion and high temperatures. Don't compromise on quality - choose the DIB-1 Casting Steel Trunnion Mounted Ball Valve for your next project.
Categories
Trunnion Mounted Ball Valve
Tags:
Trunnion Ball Valve
, ASTM A216 WCB Ball Valve
, 6 Inch Ball Valve
.
DIB-1 Casting Steel Trunnion Mounted Ball Valve, API 6D, 6 Inch, 600 LB, RF, WCB body, F6A trim, PEEK Seat
Valve Description:
1811013 Trunnion Mounted Ball Valve 6BS6RWCB-DIB1
Design Standard: API 6D
Structure: Two pieces body, Side Entry, Bolted Bonnet, Soft DPE Seat
Nominal size: 6 Inch
Nominal class: 600 LB
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Gear
Body Material: ASTM A216 WCB
Trim Material: ASTM A182 F6A, PEEK Seat
Face to face: ASME B16.10
Test and inspection: API 598, API 6D
Key Features: Double-Isolation and Bleed (DIB), Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 24 Inch (DN15 - DN1200)
Pressure range: Class 150 - 900 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +150℃
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
