DSS Lug Butterfly Valve, CL 300, 24 IN, ASTM A890 4A, EN 593

Home/Products/Butterfly Valves/Double Offset Butterfly Valve/DSS Lug Butterfly Valve, CL 300, 24 IN, ASTM A890 4A, EN 593
DSS Lug Butterfly Valve, CL 300, 24 IN, ASTM A890 4A, EN 593

Key Specifications / Features

Model No. : 1862360
We offer double offset lug butterfly valves built to API 609 Category B and EN 593 standards. Our 24-inch, Class 300 LB valves feature a double eccentric design, constructed from ASTM A890 4A material with a corrosion-resistant Monel K500 stem. Engineered for long working life with millions of cycles, these valves deliver low torque operation, a replaceable seat, tight bi-directional sealing under full pressure, and excellent control characteristics. Fire-safe seat options are also available, making them ideal for demanding industrial applications. As a leading butterfly valve manufacturer in China, we are committed to delivering high-quality, reliable products.

Detail Information

API 609 Category B Butterfly Valve, Lug End, 24 Inch/DN600, 300 LB, Double Eccentric.

Valve Description

1862360 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Nominal Size: 24 Inch, DN600
Nominal Class: Class 300 LB, PN50
Structure: Double Offset, Double Eccentric
Body Material: ASTM A890 4A, Titanium, ASTM A351 CF8M, ASTM A216 WCB, ASTM A351 CF8, ASTM B148 C95800, ASTM A890 5A.
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Seat: RPTFE, PPL
End Connection: Lug
Operation: Gear
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 IN - 48 IN (DN15 - DN1200)
Pressure Range: CL 150  - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Bosseal Valve advantages: 0 Leakage, low Torque, Long working life, Low Emission, Bi-direction and Fire Safe Design.
