Flexible Wedge Gate Valve, Aluminum Bronze, API 600, 12 Inch

Key Specifications / Features

Model no. : GTV-187304008

We are a leading manufacturer of flexible wedge gate valves crafted from high-quality aluminum bronze ASTM B148 C95800, designed to meet API 600 standards. This 12-inch valve is ideal for corrosive environments, offering excellent resistance to seawater and harsh media. It features a pressure seal bonnet for enhanced sealing under high pressure, along with an OS&Y design for clear stem visibility and dependable operation. Rated for Class 150 LB, the valve is available with flat face (FF) or raised face (RF) flanged ends, making it a reliable choice for marine and industrial applications.


Detail Information

Valve Description:
187304008 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 12 Inch, DN300
Nominal Class: Class 150 LB, Class 300 LB
Bore Type: Standard Bore(API 600)
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service

Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Handwheel/Gear/Motor
