Key Specifications / Features
As a leading forged ball valve manufacturer in China, we specialize in high-performance valves designed to meet API 6A and API 6D standards for critical industrial applications. Our valves feature robust ASTM A694 F60 or F65 bodies with 7-1/16 inch sizes, capable of handling pressures up to 2000 PSI. The trim is crafted from durable 17-4PH stainless steel or Inconel, ensuring long-lasting reliability in demanding environments. Available with BW (butt-weld) ends and a range of seat materials including PEEK, POM, TCC, or STL, these valves provide precise flow control, exceptional sealing, and safe operation across challenging oilfield and industrial applications.
Valve Description:
181105014 API 6A Compact Ball Valve
Design Standard: API 6A/API 6D
Structure: 1pc body
Body Material: AISI 4130/ASTM A694 F60/A694 F65
Trim Material: AISI 4140/F51/17-4PH/Inconel Trim
Nominal Size: 1-13/16 Inch to 11 Inch
Nominal Class: 2000-15000 PSI
Bore Type: Full Bore or Reduced Bore
End Connection: RTJ, BW, and Hub
Operation: Lever/Gear/Bare Shaft
Test and Inspection: API 6A/API 6D
Seat Insert: POM/PEEK or hard faced
Face to Face: ASME B16.10/MFG'S
Key Features:
Compact design with short face to face and low weight
Low torque
Easy for maintenance
Removable seat retainer to reduce torque and easy for repair
• Material Class: AA, BB, CC, DD, EE, FF, HH
• Temperature Class: L, N, P, S, T, U, V, X, Y
• Specification: PSL1 - PSL3G
• Performance: PR1, PR2
Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1-13/16 - 11 Inch
Pressure Range: 2000PSI - 15000PSI
End Connection: RF, RTJ, BW, HUB
Working Temperature: -26°C - +150°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
