Forged Floating Ball Valve, API 6D, CF8M, 1-1/2 Inch, 2pcs

Key Specifications / Features

Model No. : 181203004

This 1-1/2 Inch (DN40) Forged Floating Ball Valve is designed to meet API 6D, API 608, and ISO 17292 standards, providing reliable performance in a wide range of industrial applications. Featuring a two-piece side-entry body made from durable ASTM A351 CF8M stainless steel, it ensures excellent corrosion resistance and long service life. The valve is equipped with RF flanged ends for secure installation and a Class 150 LB rating for safe operation under moderate pressure. As a leading Forged Floating Ball Valve supplier in China, we deliver high-quality, precision-engineered valves for consistent, efficient, and reliable flow control.


Detail Information

Valve Description:
181203004 Floating Ball Valve
Design Standard: ISO 17292, API 608, API 6D
Structure: 2pcs body, Side Entry, Bolted Bonnet, Soft Seat
Sizes: 1-1/2 Inch, DN40, 40 mm
Pressure Rating: Class 150 LB, PN20
Bore Type: Full Bore or Reduced Bore
End Connection: RF, RTJ
Operation: Lever
Body Material: ASTM A105N or A350 LF2 or A182 F316, WCB, WCC, LCB, LCC, CF8, CF8M, CF3, CF3M, A995 4A, A995 5A, A995 6A, C95800
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55, A105+ENP, LF2+ENP
Seat Insert: RPTFE, DEVLON, NYLON, PEEK
Face to face: Manufacturer Standard
Test and inspection: API 598, API 6D
Key Features: Anti-static, Fire Safe, Anti-Blowout Stem

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 Inch - 6 Inch (DN15 – DN150)
Pressure range: Class 150 LB - 300 LB
End connection: Flanged
Working temperature: -26°C - +210°C
Operation: Manual(lever), Pneumatic Actuator
